ProSecure Unified Threat Management (UTM) Appliance Reference Manual
Monitoring System Access and Performance 11-21
v1.0, January 2010
Table 11-9 explains the fields of the Status and System Information sections of the System Status
screen.
Figure 11-10 [System Status, screen 1 of 3]
Table 11-9. System Status: Status and System Information
Setting Description (or Subfield and Description)
Status
System The current CPU, memory, and hard disk usage. When usage is within safe
limits, the status bars show green.
Services The protocols that are being scanned for malware threats (ON or OFF stated
next to the protocol) and the number of active connections for each protocol.
