ProSecure Unified Threat Management (UTM) Appliance Reference Manual
8-34 Virtual Private Networking Using SSL Connections
v1.0, January 2010
.
3. Select the radio buttons, complete the fields, and make your selection from the pull-down
menus as explained Table 8-10.
Figure 8-19
Table 8-10.
Add Policy Settings
Item Description (or Subfield and Description)
Policy For
Select one of the following radio buttons to specify the type of SSL VPN policy:
• Global. The new policy is global and excludes all groups and users.
• Group. The new policy must be limited to a single group. From the pull-down menu, select a group
name.
Note: For information about how to create groups, see “Configuring Groups for VPN Policies” on
page 9-6.
• User. The new policy must be limited to a single user. From the pull-down menu, select a user name.
Note: For information about how to create user accounts, see “Configuring User Accounts” on
page 9-9.
